The DM3000 Series Digital Multimeters give reliable, cost effective, full DMM capabilities measuring DCV, ACV, DCI, ACI, Resistance (2 & 4 Wire), Capacitance, Diode Test, Frequency, and Temperature. These Digital Multimeters are designed for simple and efficient bench top use, but include software options for datalogging and remote programming from almost any interface. 5.5 digits 8 uV noise floor 1 channel Standard Interfaces: USB Device, USB Host, RS-232

The DM3000 Series Digital Multimeters give reliable, cost effective, full DMM capabilities measuring DCV, ACV, DCI, ACI, Resistance (2 & 4 Wire), Capacitance, Diode Test, Frequency, and Temperature. These Digital Multimeters are designed for simple and efficient bench top use, but include software options for datalogging and remote programming from almost any interface. 6.5 digits 5 uV noise floor 1 channel Standard Interfaces: USB Device, USB Host, LAN, RS-232, GPIB, support U-disc storage and Web remote control (LXI-C)

Rigol's DSA815 spectrum analyzer redefines the product category by setting new standards for performance and price. The DSA815 features a unique widescreen display, compact design and easy-to-use interface and operations, making it ideal for benchtop or field apps in RF and wireless testing and production. The new spectrum analyzer offers the ability to measure smaller signals using our digital IF filter, which allows for smaller bandwidth settings and reduces displayed noise levels. Frequency Range from 9 kHz up to 1.5 GHz Min. -155 dBm Displayed Average Noise Level (Typ.) Min. -80 dBc/Hz @ 10 kHz Offset Phase Noise 10 Hz Minimum Resolution Bandwidth

Rigol's DSA815 spectrum analyzer redefines the product category by setting new standards for performance and price. The DSA815 features a unique widescreen display, compact design and easy-to-use interface and operations, making it ideal for benchtop or field apps in RF and wireless testing and production. The new spectrum analyzer offers the ability to measure smaller signals using our digital IF filter, which allows for smaller bandwidth settings and reduces displayed noise levels. Frequency Range from 9 kHz up to 1.5 GHz Min. -155 dBm Displayed Average Noise Level (Typ.) Min. -80 dBc/Hz @ 10 kHz Offset Phase Noise 10 Hz Minimum Resolution Bandwidth Built-in 1.5 GHz tracking generator

Instrument Carry Case for a DSA800 Spectrum Analyzer, DG4000 generator, or DS2000 scope.

RP1000D series high voltage differential probe can convert high differential input voltage to low voltage and display the waveform on the oscilloscope. Its working frequency is up to 25MHz(RP1025D), 50MHz(RP1050D) and 100MHz(RP1100D) and it is rather suitable forlarge electricity test and R&D. RP1000D series high voltage differential probe is applicable to general purpose oscilloscope and the labeled attenuation ratios are those when the input impedance of the oscilloscope is 1MO. Theattenuation ratios will double when the input impedance of the oscilloscope is 50O. Frequency Range: DC to 50 MHz Input Voltage Range: 7000 Vpp

The RP1001C current probe enables a general purpose oscilloscope to display AC and DC current signals up to 100 A Peak (70 A RMS). The RP1001C current probe can also make AC and DC measurements with a multimeter by using the BNC-to-banana plug adapter. DC and AC Frequency range: DC to 300KHz Ranges of 0.01V/A,0.1V/A Battery powered 9V internal for maximum external noise supression

Free Options Bundle for all 2000A Models All options now come standard, which includes: serial decode, deep memory, record mode, and advanced triggering. MSO2000A series is the new mainstream digital scope to meet the customer's applications with its innovative technology. MSO2000A series has 2+16 channels, target for the embedded design and test market with its industry leading specifications, powerful trigger functions and broad analysis capabilities. Bandwidth - 300 MHz Analog Channels - 2 CH Digital Channels - 16 CH Max. Sample Rate: 2 GSa/s 14 Mpts Memory Depth Waveform capture rate up to 50,000 wfms/s

Passive High Voltage Probe for use with Rigol Oscilloscopes Bandwidth: DC-300 MHz Attenuation Ratio: 100:1 Max. Input voltage CAT|2000V(DC+AC) CAT||1500V(DC+AC)

The coaxial fixed attenuator is applicable to the situations that require power level reduction and circuit matching. It can absorb the energy of the transmission wires quantitatively, extend the power range, control the power level and make precise measurements of the power and amplitude of various signal generators by working with small power meter, multimeter or oscilloscope. Frequency Range: DC to 1 GHz Attenuation Value: 40 dB Impedance: 50 O Power: 1 W

Data Acquisiton System 5 Slot System - no included modules

NFP-3 is used with RIGOL DSA series spectrum analyzer for the EMI tests of electronic products. It can be used to test the magnetic field strength and magnetic field coupling channels on the surface of the electronic components as well as the magnetic field environment near the electronic module so as to quickly locate the interference source. Frequency Range: 30MHz to 3GHz One set includes four types of probe, provides optimizing sensitivity and resolution Minimum resolution: 2mm; able to capture near field radiation of single circuit line

The DS1074Z Plus is one of Rigol's economical digital oscilloscopes. It offers unprecedented value in customer applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The 4-channel, 70 MHz, upgradable to MSO version with the purchase of the RPL1116 digital lead kit scope has a 7-inch display with Rigol's UltraVision technology, as well as a host of options. 70 MHz bandwidth 4 analog channels Upgradable to 16 digital channels (requires optional RPL1116 logic probe to operate) Real-time sample rate up to 1 GSa/s 24 Mpts with the deep memory option Up to 30,000 wfms/s waveform capture rate Low noise floor, vertical scale range: 1 mV/div to 10 V/div Various interfaces: USB Host&Device, LAN (LXI), AUX Free Options Bundle for all 1000Z Models All options now come standard and factory installed, which includes: serial decode, deep memory, record mode, and advanced triggering. This free bundle is a $450.00 value! Models and Comparisons Model DS1054Z DS1074Z Plus DS1074Z-S Plus DS1104Z Plus DS1104Z-S Plus Analog Bandwidth 50 MHz 70 MHz 100 MHz Number of Analog Channels 4 Number of Digital Channels None DS1000Z Plus supports 16 digital channels after being upgraded with the MSO upgrade option Max. Real-time Sample Rate Analog: 1 GSa/s (1-ch), 500 MSa/s (2-ch), 250 MSa/s (3/4-ch) Digital: 1 GSa/s (8-ch), 500 MSa/s (16-ch) Max. Memory Depth Analog: 24 Mpts (1-ch), 12 Mpts (2-ch), 6 Mpts (3/4-ch) Digital: 24 Mpts (8-ch), 12 Mpts (16-ch) Max. Waveform Capture Rate 30,000 wfms/s Hardware Real-time Waveform Recording and Playback Functions Up to 60,000 frames Standard Probes 4 sets of PVP3150 150 MHz Passive HighZ Probes Built-in 2Ch 25MHz Source No No Yes No Yes

Free Options Bundle for all 2000A Models All options now come standard, which includes: serial decode, deep memory, record mode, and advanced triggering. MSO2000A series is the new mainstream digital scope to meet the customer's applications with its innovative technology. MSO2000A series has 2+16 channels, target for the embedded design and test market with its industry leading specifications, powerful trigger functions and broad analysis capabilities. Bandwidth - 300 MHz Analog Channels - 2 CH Digital Channels - 16 CH Built in 2 channel 25MHz waveform generator Max. Sample Rate: 2 GSa/s 14 Mpts Memory Depth Waveform capture rate up to 50,000 wfms/s

The DS1104Z-S Plus is one of Rigol's economical digital oscilloscopes. It offers unprecedented value in customer applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The 4-channel, 100 MHz, upgradable to MSO version with the purchase of the RPL1116 digital lead kit scope has a 7-inch display with Rigol's UltraVision technology, as well as a host of options. 100 MHz bandwidth 4 analog channels Upgradable to 16 digital channels (requires optional RPL1116 logic probe to operate) Built in 2 channel 25MHz waveform generator Real-time sample rate up to 1 GSa/s 12 Mpts Memory Depth, 24 Mpts with the deep memory option Up to 30,000 wfms/s waveform capture rate Low noise floor, vertical scale range: 1 mV/div to 10 V/div Various interfaces: USB Host&Device, LAN (LXI), AUX Free Options Bundle for all 1000Z Models All options now come standard and factory installed, which includes: serial decode, deep memory, record mode, and advanced triggering. This free bundle is a $450.00 value! Models and Comparisons Model DS1054Z DS1074Z Plus DS1074Z-S Plus DS1104Z Plus DS1104Z-S Plus Analog Bandwidth 50 MHz 70 MHz 100 MHz Number of Analog Channels 4 Number of Digital Channels None DS1000Z Plus supports 16 digital channels after being upgraded with the MSO upgrade option Max. Real-time Sample Rate Analog: 1 GSa/s (1-ch), 500 MSa/s (2-ch), 250 MSa/s (3/4-ch) Digital: 1 GSa/s (8-ch), 500 MSa/s (16-ch) Max. Memory Depth Analog: 24 Mpts (1-ch), 12 Mpts (2-ch), 6 Mpts (3/4-ch) Digital: 24 Mpts (8-ch), 12 Mpts (16-ch) Max. Waveform Capture Rate 30,000 wfms/s Hardware Real-time Waveform Recording and Playback Functions Up to 60,000 frames Standard Probes 4 sets of PVP3150 150 MHz Passive HighZ Probes Built-in 2Ch 25MHz Source No No Yes No Yes

Standard logic probe for MSO1000Z. Upgrades a DS1000Z Plus or DS1000Z-S Plus to an equivalent MSO. Includes front panel labels with MSO model number. Only works with the Plus models or as a replacement part for the MSO1000Z models. 16 inputs

Rigol's DSA875 spectrum analyzer redefines the product category by setting new standards for performance and price. The DSA875 features a unique widescreen display, compact design and easy-to-use interface and operations, making it ideal for benchtop or field apps in RF and wireless testing and production. The new spectrum analyzer offers the ability to measure smaller signals using our digital IF filter, which allows for smaller bandwidth settings and reduces displayed noise levels. The DSA875 also distinguishes between signals with a frequency difference as little as 100 Hz. The DSA875 includes a wide range of standard functions including AM/FM demodulation and a preamplifier. Frequency Range from 9 kHz up to 7.5 GHz Min. -161 dBm Displayed Average Noise Level (Typ.) Min. -98 dBc/Hz @ 10 kHz Offset Phase Noise 10 Hz Minimum Resolution Bandwidth Built-in 1.5 GHz tracking generator

Maximum Frequency of 1.5 GHz High signal purity, phase noise: Amplitude accuracy: <0.5dB (typical) AM/FM/øM modulation standard. Standard pulse modulation The DSG800 series of RF signal generators offer output frequencies between 9kHz to 3.6 GHz. It offers standard AM/FM/øM modulation standard with optional Pulse modulation and customizable pulse train. The DSG800 is designed to be both highly stable and reliable. The DSG800 series is an unprecedented value for an uncompromising RF signal generator for both design and debugging applications.

Arbitrary Waveform Generator Output Frequency- SINE: 250 MHz Output Frequency- Square: 120 MHz Channels: 2 channels Arbitrary Waveform Length: 128 Mpts
