Arbitrary Waveform Generators

Waveform Generators 120MHz Max Output Frequency 2 Output Channels 1.2GSa/s Sample Rate 16 bit vertical resolution 8Mpts Arbitrary Waveform Length The SDG2000X, developed by SIGLENT, comprises a series of dual-channel function/arbitrary waveform generators featuring specifications including a maximum bandwidth of up to 120 MHz, a sampling rate of 1.2 GSa/s, and a vertical resolution of 16 bits. Leveraging the proprietary TrueArb & EasyPulse techniques, this series effectively addresses the shortcomings inherent in traditional DDS generators when generating arbitrary, square, and pulse waveforms. With these advantages, the SDG2000X is capable of delivering a diverse range of high-fidelity and low-jitter signals, meeting the escalating demands of complex and extensive applications.

Waveform Generators 80MHz Max Output Frequency 2 Output Channels 1.2GSa/s Sample Rate 16 bit vertical resolution 8Mpts Arbitrary Waveform Length The SDG2000X, developed by SIGLENT, comprises a series of dual-channel function/arbitrary waveform generators featuring specifications including a maximum bandwidth of up to 120 MHz, a sampling rate of 1.2 GSa/s, and a vertical resolution of 16 bits. Leveraging the proprietary TrueArb & EasyPulse techniques, this series effectively addresses the shortcomings inherent in traditional DDS generators when generating arbitrary, square, and pulse waveforms. With these advantages, the SDG2000X is capable of delivering a diverse range of high-fidelity and low-jitter signals, meeting the escalating demands of complex and extensive applications.

Arbitrary Waveform Generator Output Frequency- SINE: 25 MHz Output Frequency- Square: 25 MHz Channels: 2 channels Arbitrary Waveform Length: 2 Mpts

Max Frequency: 150 MHz 2 Channels Sample Rate: 1,25 GSa/s Vertical Resolution: 16 bits Waveform Memory Depth: 16 Mpts/CH (up to 32Mpts optional) The DG900 Pro series Function/Arbitrary Waveform Generator offers a sample rate of up to 1.25 GSa/s and a standard 16 Mpts/CH memory depth. This economical dual-channel function/arbitrary waveform generator integrates various functions, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator, and Counter. Features Max. sample rate: 1.25 GSa/s Max. output frequency: 200 MHz 16-bit vertical resolution Arbitrary waveform editing function with a max. Arb waveform length of 16 Mpts/CH (32 Mpts/CH optional) Built-in high-order harmonic generator (max. 20th order) Independent signal frequency measurement channel with a max. frequency of 500 MHz USB and LAN interfaces for remote connection Type-C power interface for powering the instrument with mobile power source, satisfying testing requirements in the field Standard Web Control function for easier remote cooperation

Waveform Generator 30MHz Max Output Frequency 1 Output Channel 125MSa/s Sample Rate 16Kpts Arbitrary Waveform Length The SDG800 series Function/Arbitrary Waveform Generator is a recent addition to the SIGLENT family, featuring a user-friendly design that includes a 3.5-inch TFT-LCD display. The generator comes equipped with built-in Chinese/English language options, an online help function, and supports both USB drives and internal storage for convenient file management.

Arbitrary Waveform Generator Output Frequency- SINE: 25 MHz Output Frequency- Square: 10 MHz Channels: 1 channels Arbitrary Waveform Length: 8 Mpts

Arbitrary Waveform Generator Output Frequency- SINE: 35 MHz Output Frequency- Square: 10 MHz Channels: 2 channels Arbitrary Waveform Length: 8 Mpts

Waveform Generators 30MHz Max Output Frequency 2 Output Channels 1 GSa/s Sample Rate 16 bit vertical resolution 8Mpts/CH Arbitrary Waveform Length The SIGLENT SDG1000X Plus series is a dual-channel function/arbitrary waveform generator with a maximum bandwidth of 60 MHz. It features an impressive 1 GSa/s sampling rate and 16-bit vertical resolution, ensuring high-precision signal generation. Building on traditional DDS technology, the SDG1000X Plus incorporates innovative TrueArb and EasyPulse technologies, which overcome the limitations of DDS in generating arbitrary waveforms and square/pulse signals. This results in high-fidelity, low-jitter signal output. Additionally, the SDG1000X Plus supports PRBS pattern generation, sequence waveform output, and dual-pulse output, making it a versatile solution for a wide range of applications.

Waveform Generators 25MHz Max Output Frequency 2 Output Channels 1 GSa/s Sample Rate 16 bit vertical resolution 8Mpts/CH Arbitrary Waveform Length The SIGLENT SDG1000X Plus series is a dual-channel function/arbitrary waveform generator with a maximum bandwidth of 60 MHz. It features an impressive 1 GSa/s sampling rate and 16-bit vertical resolution, ensuring high-precision signal generation. Building on traditional DDS technology, the SDG1000X Plus incorporates innovative TrueArb and EasyPulse technologies, which overcome the limitations of DDS in generating arbitrary waveforms and square/pulse signals. This results in high-fidelity, low-jitter signal output. Additionally, the SDG1000X Plus supports PRBS pattern generation, sequence waveform output, and dual-pulse output, making it a versatile solution for a wide range of applications.

Arbitrary Waveform Generator 1GHz, 5 GSa/s Sampling Rate; 14-bit Vertical Resolution; Arb-Waveform Length: 64 pts ~ 512 Mpts; 5 Inch Touch Screen

Waveform Generator 200MHz Max Output Frequency 2 Output Channels 2.4 GSa/s Sample Rate 16 bit vertical resolution 20Mpts Arbitrary Waveform Length The SDG6000X series by SIGLENT is a collection of dual-channel Pulse/Arbitrary Waveform Generators, offering specifications such as a maximum bandwidth of up to 500 MHz, a sample rate reaching 2.4 GSa/s, and a 16-bit vertical resolution. This series incorporates the proprietary TrueArb & EasyPulse technology, effectively addressing the limitations found in traditional DDS generators when generating arbitrary, square, and pulse waveforms. Notably, the SDG6000X serves as a versatile multi-function device capable of producing Noise, IQ signals, and PRBS patterns. These features empower the SDG6000X to deliver a diverse range of high-fidelity and low-jitter signals, effectively meeting the increasing demands of intricate and resource-intensive applications.

Max Frequency: 200 MHz 2 Channels Sample Rate: 1,25 GSa/s Vertical Resolution: 16 bits Waveform Memory Depth: 16 Mpts/CH (up to 32Mpts optional) The DG900 Pro series Function/Arbitrary Waveform Generator offers a sample rate of up to 1.25 GSa/s and a standard 16 Mpts/CH memory depth. This economical dual-channel function/arbitrary waveform generator integrates various functions, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator, and Counter. Features Max. sample rate: 1.25 GSa/s Max. output frequency: 200 MHz 16-bit vertical resolution Arbitrary waveform editing function with a max. Arb waveform length of 16 Mpts/CH (32 Mpts/CH optional) Built-in high-order harmonic generator (max. 20th order) Independent signal frequency measurement channel with a max. frequency of 500 MHz USB and LAN interfaces for remote connection Type-C power interface for powering the instrument with mobile power source, satisfying testing requirements in the field Standard Web Control function for easier remote cooperation

Max Frequency: 70 MHz 2 Channels Sample Rate: 1,25 GSa/s Vertical Resolution: 16 bits Waveform Memory Depth: 16 Mpts/CH (up to 32Mpts optional) The DG900 Pro series Function/Arbitrary Waveform Generator offers a sample rate of up to 1.25 GSa/s and a standard 16 Mpts/CH memory depth. This economical dual-channel function/arbitrary waveform generator integrates various functions, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator, and Counter. Features Max. sample rate: 1.25 GSa/s Max. output frequency: 200 MHz 16-bit vertical resolution Arbitrary waveform editing function with a max. Arb waveform length of 16 Mpts/CH (32 Mpts/CH optional) Built-in high-order harmonic generator (max. 20th order) Independent signal frequency measurement channel with a max. frequency of 500 MHz USB and LAN interfaces for remote connection Type-C power interface for powering the instrument with mobile power source, satisfying testing requirements in the field Standard Web Control function for easier remote cooperation

Max Frequency: 50 MHz 2 Channels Sample Rate: 625 MSa/s Vertical Resolution: 16 bits Waveform Memory Depth: 2 Mpts/CH (up to 8Mpts optional) The DG800 Pro series Function/Arbitrary Waveform Generator offers a cost-effective solution, providing a sample rate of up to 625 MSa/s and a standard 2 Mpts/CH memory depth. This versatile generator combines various functions, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator, and Counter. Features Max. sample rate: 625 MSa/s Max. output frequency: 50 MHz 16-bit vertical resolution Arbitrary waveform editing function with a max. Arb waveform length of 2 Mpts/CH (8 Mpts/CH optional) Built-in high-order harmonic generator (max. 20th order) • Independent signal frequency measurement channel with a max. frequency of 500 MHz USB and LAN interfaces for remote connection Type-C power interface for powering the instrument with mobile power source, satisfying testing requirements in the field Standard Web Control function for easier remote cooperation

Max Frequency: 25 MHz 2 Channels Sample Rate: 625 MSa/s Vertical Resolution: 16 bits Waveform Memory Depth: 2 Mpts/CH (up to 8Mpts optional) The DG800 Pro series Function/Arbitrary Waveform Generator offers a cost-effective solution, providing a sample rate of up to 625 MSa/s and a standard 2 Mpts/CH memory depth. This versatile generator combines various functions, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator, and Counter. Features Max. sample rate: 625 MSa/s Max. output frequency: 50 MHz 16-bit vertical resolution Arbitrary waveform editing function with a max. Arb waveform length of 2 Mpts/CH (8 Mpts/CH optional) Built-in high-order harmonic generator (max. 20th order) • Independent signal frequency measurement channel with a max. frequency of 500 MHz USB and LAN interfaces for remote connection Type-C power interface for powering the instrument with mobile power source, satisfying testing requirements in the field Standard Web Control function for easier remote cooperation

RF Signal Generator Frequency Range: 9 KHz – 3.2 GHz Calibrated Output Range (-110 dBm – +13 dBm) (Max. level to +20 dBm (Typ.) Phase Noise: -110 dBc/Hz @ 1 GHz, 20 Khz offset (Typ.) Built-in AM, FM, PM. Optional Pulse Train Modulation External USB-Power Sensor support (Power sensor not included) Capacitive Touch Display / Web Browser Based Remote Control SIGLENT's SSG3000X series of signal generators cover a frequency range from 9 kHz to 2.1 GHz/3.2 GHz. These generators offer standard analog modulation options such as AM, FM, and PM, along with pulse modulation and a pulse train generator. Additionally, when coupled with a baseband generator like the SDG6000X, they can produce IQ modulated signals. The SSG3000X series, known for their high accuracy and pure outputs, are ideal for applications in research and development, education, and manufacturing. Key Features: - Frequency Setting Resolution: 0.01 Hz - Output Level: -110 dBm to +13 dBm - Maximum Level: Up to +20 dBm (typical) - Phase Noise: -110 dBc/Hz @ 1 GHz, 20 kHz offset (typ.) - Level Accuracy: ≤0.7 dB (typical) - Analog Modulation: AM, FM, PM (Internal, External, or Int+Ext source) - Pulse Modulation: On/Off ratio ≥70 dBc - Pulse Train Generator (Option) - External IQ Modulation with SDG6000X as the Baseband IQ Signal - USB Power Meter Measurement - 5-inch TFT Capacitive Touch Screen, Mouse, and Keyboard Supported - Web Browser Remote Control on PC and Mobile Terminals - Standard Interfaces: USB Host, USB Device (USB TMC), LAN (VXI-11, Socket, Telnet) - Optional Interface: GPIB

Waveform Generator 350MHz Max Output Frequency 2 Output Channels 2.4 GSa/s Sample Rate 16 bit vertical resolution 20Mpts Arbitrary Waveform Length The SDG6000X series by SIGLENT is a collection of dual-channel Pulse/Arbitrary Waveform Generators, offering specifications such as a maximum bandwidth of up to 500 MHz, a sample rate reaching 2.4 GSa/s, and a 16-bit vertical resolution. This series incorporates the proprietary TrueArb & EasyPulse technology, effectively addressing the limitations found in traditional DDS generators when generating arbitrary, square, and pulse waveforms. Notably, the SDG6000X serves as a versatile multi-function device capable of producing Noise, IQ signals, and PRBS patterns. These features empower the SDG6000X to deliver a diverse range of high-fidelity and low-jitter signals, effectively meeting the increasing demands of intricate and resource-intensive applications.

Waveform Generators 40MHz Max Output Frequency 2 Output Channels 1.2GSa/s Sample Rate 16 bit vertical resolution 8Mpts Arbitrary Waveform Length The SDG2000X, developed by SIGLENT, comprises a series of dual-channel function/arbitrary waveform generators featuring specifications including a maximum bandwidth of up to 120 MHz, a sampling rate of 1.2 GSa/s, and a vertical resolution of 16 bits. Leveraging the proprietary TrueArb & EasyPulse techniques, this series effectively addresses the shortcomings inherent in traditional DDS generators when generating arbitrary, square, and pulse waveforms. With these advantages, the SDG2000X is capable of delivering a diverse range of high-fidelity and low-jitter signals, meeting the escalating demands of complex and extensive applications.

Waveform Generators 60MHz Max Output Frequency 2 Output Channels 150MSa/s Sample Rate 14 bit vertical resolution 16Kpts Arbitrary Waveform Length The SDG1000X by SIGLENT is a series of dual-channel function/arbitrary waveform generators featuring specifications such as a maximum bandwidth of up to 60 MHz, a sampling rate of 150 MSa/s, and a vertical resolution of 14 bits. Utilizing the proprietary EasyPulse & TrueArb technique, this series addresses the inherent weaknesses of traditional DDS generators when generating pulse and arbitrary waveforms. The dedicated square generator within the SDG1000X is capable of producing square waveforms with frequencies up to 60 MHz and low jitter. With these advantages, the SDG1000X caters to users by delivering a diverse range of high-fidelity/low-jitter signals, meeting the evolving demands of various complex applications.

Waveform Generator 10MHz Max Output Frequency 1 Output Channel 125MSa/s Sample Rate 16Kpts Arbitrary Waveform Length The SDG800 series Function/Arbitrary Waveform Generator is a recent addition to the SIGLENT family, featuring a user-friendly design that includes a 3.5-inch TFT-LCD display. The generator comes equipped with built-in Chinese/English language options, an online help function, and supports both USB drives and internal storage for convenient file management.

Arbitrary Waveform Generator Output Frequency- SINE: 70 MHz Output Frequency- Square: 20 MHz Channels: 2 channels Arbitrary Waveform Length: 16 Mpts

Arbitrary Waveform Generator Output Frequency- SINE: 100 MHz Output Frequency- Square: 25 MHz Channels: 2 channels Arbitrary Waveform Length: 16 Mpts

Arbitrary Waveform Generator Output Frequency- SINE: 50 MHz Output Frequency- Square: 15 MHz Channels: 2 channels Arbitrary Waveform Length: 16 Mpts

Arbitrary Waveform Generator Output Frequency- SINE: 10 MHz Output Frequency- Square: 5 MHz Channels: 2 channels Arbitrary Waveform Length: 8 Mpts
