Digital Oscilloscopes

70 MHz bandwidth 4 analog channels 1.25 GSa/s real-time sample rate 25 Mpts memory depth 12 bit vertical resolution 1,000,000 wfms/s in Ultra Acquire Mode Compact size The DHO800 series from RIGOL embodies their latest addition: a digital oscilloscope that combines high performance with affordability. Despite its small size, this oscilloscope stands out for its exceptional capabilities, including a capture rate of up to 1,000,000 waveforms per second (in UltraAcquire Mode), a 25 Mpts memory depth, 12-bit resolution, and minimal noise. The DHO800 impressively maintains a compact form factor while boasting a wealth of features. A quick comparison with the DHO1000 readily reveals the noticeable difference in size. DHO800 vs DHO1000 DHO800 vs Standard Notebook The small form factor easily allows the DHO800 to be used as a portable handheld instrument that can be powered by a battery bank. Features Ultra-low noise floor, purer signal, never miss the small signals Up to 12 bits resolution for all the models of this series Max. real-time sample rate of 1.25 GSa/s Max. memory depth of 25 Mpts Vertical sensitivity range: 500 μV/div to 10 V/div Max. capture rate of 1,000,000 wfms/s (in UltraAcquire mode) Digital phosphor display with real-time 256-level intensity grading Waveform search and navigation function allows you to debug the signal anomalies faster 7" (1024x600) capacitive multi-touch screen Brand new Flex Knob brings a user-friendly experience USB Device & Host, LAN, and HDMI interfaces (std.) for all the models of this series Novel and delicate industrial design, easy to operate Unique online upgrade

Digital Oscilloscope 70 MHz Bandwidth 4 Channels 12 Bit 2GSa/s sample rate The SDS800X HD series of high-resolution digital storage oscilloscopes from SIGLENT utilize 2 GSa/s, 12-bit Analog-Digital Converters, and front ends known for their exceptional noise floor performance. These oscilloscopes are offered in bandwidths of 200 MHz, 100 MHz, and 70 MHz, featuring a maximum record length of 100 Mpts. They provide the capability to display 2/4 analog channels alongside 16 digital channels for mixed signal analysis. Incorporating Siglent’s SPO technology, the SDS800X HD series boasts a maximum waveform capture rate of up to 120,000 wfm/s in normal mode (up to 500,000 wfm/s in Sequence mode). The oscilloscopes also feature a 256-level intensity grading display function and a color temperature display mode. An innovative digital trigger system with high sensitivity and low jitter is employed, supporting various powerful triggering modes, including serial bus triggering. These oscilloscopes come equipped with tools such as History waveform recording, Search and Navigate functions, Mask Test, Bode Plot, and Power Analysis, enabling the capture, storage, and analysis of extended waveform records. Additionally, the SDS800X HD series offers an extensive range of measurement and mathematical capabilities, options for a 25 MHz arbitrary waveform generator, and support for serial decoding. The 7″ display capacitive touch screen supports multi-touch gestures and features a user-friendly UI design to enhance operational efficiency. The oscilloscopes also support mouse control and allow for remote web control over LAN.

The DS1054Z is Rigol's most popular, economical digital oscilloscope. It offers unprecedented value in customer applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The 4-channel, 50 MHz scope has a 7-inch display with Rigol's UltraVision technology, as well as a host of options. 50 MHz bandwidth 4 analog channels 1 GSa/s Real Time Sample Rate 24 Mpts with the deep memory option 30,000 wfms/s Innovative "UltraVision" technology Serial Triggering and Analysis Options Free Options Bundle for all 1000Z Models All options now come standard and factory installed, which includes: serial decode, deep memory, record mode, and advanced triggering. This free bundle is a $450.00 value! Innovative UltraVision Technology Deep Memory Depth (up to 24 Mpts) Higher Waveform Capture Rate (up to 30,000 wfms/s) Real-time Waveform Recording&Playback (up to 60,000 frames) Intensity Graded Color Display Included in the Box Power Cord USB Cable 4 Passive Probes (150 MHz) - PVP3150 Quick Guide Warranty 3 Year Warranty, 1 Year Warranty for accessories such as probes. Models and Comparisons Model DS1054Z DS1074Z Plus DS1074Z-S Plus DS1104Z Plus DS1104Z-S Plus Analog Bandwidth 50 MHz 70 MHz 100 MHz Number of Analog Channels 4 Number of Digital Channels None DS1000Z Plus supports 16 digital channels after being upgraded with the MSO upgrade option Max. Real-time Sample Rate Analog: 1 GSa/s (1-ch), 500 MSa/s (2-ch), 250 MSa/s (3/4-ch) Digital: 1 GSa/s (8-ch), 500 MSa/s (16-ch) Max. Memory Depth Analog: 24 Mpts (1-ch), 12 Mpts (2-ch), 6 Mpts (3/4-ch) Digital: 24 Mpts (8-ch), 12 Mpts (16-ch) Max. Waveform Capture Rate 30,000 wfms/s Hardware Real-time Waveform Recording and Playback Functions Up to 60,000 frames Standard Probes 4 sets of PVP3150 150 MHz Passive HighZ Probes Built-in 2Ch 25MHz Source No No Yes No Yes

250 MHz bandwidth 4 analog channels 16 Digital Channels (PLA2216 logic analyzer probe required) S = Single-channel arbitrary function generator (AFG) output 1.25 GSa/s real-time sample rate 50 Mpts memory depth 12 bit vertical resolution 1,000,000 wfms/s in Ultra Acquire Mode Compact size RIGOL has unveiled its latest addition, the DHO900 series, a digital oscilloscope that combines high performance with affordability, despite its compact design. This series stands out for its exceptional capabilities, including an impressive capture rate of up to 1,000,000 waveforms per second (in UltraAcquire Mode), a generous 50 Mpts memory depth, 12-bit resolution, and minimal noise. What distinguishes the DHO900 series is its support for 16 digital channels, enabling comprehensive analysis of both analog and digital signals, making it an ideal choice for embedded design and testing scenarios. It goes further by offering features like auto serial and parallel bus analysis, bode plot analysis, and various other functions typically reserved for higher-end instruments. Remarkably, all of these features are available at an affordable price point comparable to that of entry-level instruments, making it a versatile solution for meeting testing requirements in fields such as research and development, education, and scientific research. The DHO900 impressively maintains a compact form factor while boasting a wealth of features. A quick comparison with the DHO4000 readily reveals the noticeable difference in size. DHO900 vs DHO4000 DHO900 vs Standard Notebook The small form factor easily allows the DHO900 to be used as a portable handheld instrument that can be powered by a battery bank. Features Ultra-low noise floor, purer signal, never miss the small signals Up to 12 bits resolution for all the models of this series 16 digital channels (std.), logic probe required to be purchased if needed Single-channel arbitrary function generator (AFG) output Max. real-time sample rate of 1.25 GSa/s Max. memory depth of 50 Mpts Vertical sensitivity range: 200 μV/div to 10 V/div Max. capture rate of 1,000,000 wfms/s (in UltraAcquire mode) Digital phosphor display with real-time 256-level intensity grading 7" (1024x600) capacitive multi-touch screen Brand new Flex Knob brings a user-friendly experience USB Device & Host, LAN, and HDMI interfaces (std.) for all the models of this series Novel and delicate industrial design, easy to operate Unique online upgrade

100 MHz bandwidth 4 analog channels 1.25 GSa/s real-time sample rate 25 Mpts memory depth 12 bit vertical resolution 1,000,000 wfms/s in Ultra Acquire Mode Compact size The DHO800 series from RIGOL embodies their latest addition: a digital oscilloscope that combines high performance with affordability. Despite its small size, this oscilloscope stands out for its exceptional capabilities, including a capture rate of up to 1,000,000 waveforms per second (in UltraAcquire Mode), a 25 Mpts memory depth, 12-bit resolution, and minimal noise. The DHO800 impressively maintains a compact form factor while boasting a wealth of features. A quick comparison with the DHO1000 readily reveals the noticeable difference in size. DHO800 vs DHO1000 DHO800 vs Standard Notebook The small form factor easily allows the DHO800 to be used as a portable handheld instrument that can be powered by a battery bank. Features Ultra-low noise floor, purer signal, never miss the small signals Up to 12 bits resolution for all the models of this series Max. real-time sample rate of 1.25 GSa/s Max. memory depth of 25 Mpts Vertical sensitivity range: 500 μV/div to 10 V/div Max. capture rate of 1,000,000 wfms/s (in UltraAcquire mode) Digital phosphor display with real-time 256-level intensity grading Waveform search and navigation function allows you to debug the signal anomalies faster 7" (1024x600) capacitive multi-touch screen Brand new Flex Knob brings a user-friendly experience USB Device & Host, LAN, and HDMI interfaces (std.) for all the models of this series Novel and delicate industrial design, easy to operate Unique online upgrade

70 MHz bandwidth 2 analog channels 1.25 GSa/s real-time sample rate 25 Mpts memory depth 12 bit vertical resolution 1,000,000 wfms/s in Ultra Acquire Mode Compact size The DHO800 series from RIGOL embodies their latest addition: a digital oscilloscope that combines high performance with affordability. Despite its small size, this oscilloscope stands out for its exceptional capabilities, including a capture rate of up to 1,000,000 waveforms per second (in UltraAcquire Mode), a 25 Mpts memory depth, 12-bit resolution, and minimal noise. The DHO800 impressively maintains a compact form factor while boasting a wealth of features. A quick comparison with the DHO1000 readily reveals the noticeable difference in size. DHO800 vs DHO1000 DHO800 vs Standard Notebook The small form factor easily allows the DHO800 to be used as a portable handheld instrument that can be powered by a battery bank. Features Ultra-low noise floor, purer signal, never miss the small signals Up to 12 bits resolution for all the models of this series Max. real-time sample rate of 1.25 GSa/s Max. memory depth of 25 Mpts Vertical sensitivity range: 500 μV/div to 10 V/div Max. capture rate of 1,000,000 wfms/s (in UltraAcquire mode) Digital phosphor display with real-time 256-level intensity grading Waveform search and navigation function allows you to debug the signal anomalies faster 7" (1024x600) capacitive multi-touch screen Brand new Flex Knob brings a user-friendly experience USB Device & Host, LAN, and HDMI interfaces (std.) for all the models of this series Novel and delicate industrial design, easy to operate Unique online upgrade

The DS1202Z-E is a reliable and easy to use oscilloscope at an unprecedented value for 200MHz bandwidth. The DS1000Z-E series is a high-performance and economically-priced oscilloscope series created for the design, debug, and educational requirements of the mainstream digital oscilloscope market. 200 MHz Bandwidth 2 Channel 1 GSa/s Real Time Sample Rate 24 Mpts with the deep memory option Up to 30,000 wfms/s waveform capture rate Innovative "UltraVision" technology Serial Triggering and Analysis Options Free Options Bundle for all 1000Z Models All options now come standard and factory installed, which includes: serial decode, deep memory, record mode, and advanced triggering. This free bundle is a $450.00 value!

250 MHz bandwidth 4 analog channels 16 Digital Channels (PLA2216 logic analyzer probe required) 1.25 GSa/s real-time sample rate 50 Mpts memory depth 12 bit vertical resolution 1,000,000 wfms/s in Ultra Acquire Mode Compact size RIGOL has unveiled its latest addition, the DHO900 series, a digital oscilloscope that combines high performance with affordability, despite its compact design. This series stands out for its exceptional capabilities, including an impressive capture rate of up to 1,000,000 waveforms per second (in UltraAcquire Mode), a generous 50 Mpts memory depth, 12-bit resolution, and minimal noise. What distinguishes the DHO900 series is its support for 16 digital channels, enabling comprehensive analysis of both analog and digital signals, making it an ideal choice for embedded design and testing scenarios. It goes further by offering features like auto serial and parallel bus analysis, bode plot analysis, and various other functions typically reserved for higher-end instruments. Remarkably, all of these features are available at an affordable price point comparable to that of entry-level instruments, making it a versatile solution for meeting testing requirements in fields such as research and development, education, and scientific research. The DHO900 impressively maintains a compact form factor while boasting a wealth of features. A quick comparison with the DHO4000 readily reveals the noticeable difference in size. DHO900 vs DHO4000 DHO900 vs Standard Notebook The small form factor easily allows the DHO900 to be used as a portable handheld instrument that can be powered by a battery bank. Features Ultra-low noise floor, purer signal, never miss the small signals Up to 12 bits resolution for all the models of this series 16 digital channels (std.), logic probe required to be purchased if needed Max. real-time sample rate of 1.25 GSa/s Max. memory depth of 50 Mpts Vertical sensitivity range: 200 μV/div to 10 V/div Max. capture rate of 1,000,000 wfms/s (in UltraAcquire mode) Digital phosphor display with real-time 256-level intensity grading 7" (1024x600) capacitive multi-touch screen Brand new Flex Knob brings a user-friendly experience USB Device & Host, LAN, and HDMI interfaces (std.) for all the models of this series Novel and delicate industrial design, easy to operate Unique online upgrade

Digital Oscilloscope 200 MHz Bandwidth 4 Channels 12 Bit 2GSa/s sample rate 100 Mpts memory depth 10.1" touchscreen SIGLENT's SDS1000X HD series of high-resolution digital storage oscilloscopes utilize 2 GSa/s, 12-bit Analog-Digital Converters, and front ends known for their exceptional noise floor performance. These oscilloscopes are offered in bandwidths of 200 MHz and 100 MHz, featuring a maximum record length of 100 Mpts and the ability to display 2/4 analog channels alongside 16 digital channels for mixed signal analysis. The SDS1000X HD series incorporates Siglent's SPO technology, boasting a maximum waveform capture rate of up to 120,000 wfm/s in normal mode (up to 500,000 wfm/s in Sequence mode). These oscilloscopes also feature a 256-level intensity grading display function and a color temperature display mode. An innovative digital trigger system with high sensitivity and low jitter is employed, supporting various powerful triggering modes, including serial bus triggering. Equipped with tools such as History waveform recording, Search and Navigate functions, Mask Test, Bode Plot, and Power Analysis, the SDS1000X HD series allows for the capture, storage, and analysis of extended waveform records. Additionally, these oscilloscopes offer an impressive array of measurement and mathematical capabilities, options for a 25 MHz arbitrary waveform generator, and support for serial decoding. The large 10.1" capacitive touch screen display supports multi-touch gestures and features a user-friendly UI design, significantly enhancing operational efficiency. Furthermore, it supports mouse control and allows for remote web control over LAN.

Digital Oscilloscope 100 MHz Bandwidth 4 Channels 12 Bit 2GSa/s sample rate The SDS800X HD series of high-resolution digital storage oscilloscopes from SIGLENT utilize 2 GSa/s, 12-bit Analog-Digital Converters, and front ends known for their exceptional noise floor performance. These oscilloscopes are offered in bandwidths of 200 MHz, 100 MHz, and 70 MHz, featuring a maximum record length of 100 Mpts. They provide the capability to display 2/4 analog channels alongside 16 digital channels for mixed signal analysis. Incorporating Siglent’s SPO technology, the SDS800X HD series boasts a maximum waveform capture rate of up to 120,000 wfm/s in normal mode (up to 500,000 wfm/s in Sequence mode). The oscilloscopes also feature a 256-level intensity grading display function and a color temperature display mode. An innovative digital trigger system with high sensitivity and low jitter is employed, supporting various powerful triggering modes, including serial bus triggering. These oscilloscopes come equipped with tools such as History waveform recording, Search and Navigate functions, Mask Test, Bode Plot, and Power Analysis, enabling the capture, storage, and analysis of extended waveform records. Additionally, the SDS800X HD series offers an extensive range of measurement and mathematical capabilities, options for a 25 MHz arbitrary waveform generator, and support for serial decoding. The 7″ display capacitive touch screen supports multi-touch gestures and features a user-friendly UI design to enhance operational efficiency. The oscilloscopes also support mouse control and allow for remote web control over LAN.

Digital Oscilloscope 200 MHz Bandwidth 4 Channels 12 Bit 2GSa/s sample rate The SDS800X HD series of high-resolution digital storage oscilloscopes from SIGLENT utilize 2 GSa/s, 12-bit Analog-Digital Converters, and front ends known for their exceptional noise floor performance. These oscilloscopes are offered in bandwidths of 200 MHz, 100 MHz, and 70 MHz, featuring a maximum record length of 100 Mpts. They provide the capability to display 2/4 analog channels alongside 16 digital channels for mixed signal analysis. Incorporating Siglent’s SPO technology, the SDS800X HD series boasts a maximum waveform capture rate of up to 120,000 wfm/s in normal mode (up to 500,000 wfm/s in Sequence mode). The oscilloscopes also feature a 256-level intensity grading display function and a color temperature display mode. An innovative digital trigger system with high sensitivity and low jitter is employed, supporting various powerful triggering modes, including serial bus triggering. These oscilloscopes come equipped with tools such as History waveform recording, Search and Navigate functions, Mask Test, Bode Plot, and Power Analysis, enabling the capture, storage, and analysis of extended waveform records. Additionally, the SDS800X HD series offers an extensive range of measurement and mathematical capabilities, options for a 25 MHz arbitrary waveform generator, and support for serial decoding. The 7″ display capacitive touch screen supports multi-touch gestures and features a user-friendly UI design to enhance operational efficiency. The oscilloscopes also support mouse control and allow for remote web control over LAN.

Digital Oscilloscope 100MHz Bandwidth 4 Channels 14Mpts Memory Depth SIGLENT offers the SDS1000X-E Super Phosphor Oscilloscopes in two-channel and four-channel models. The two-channel variant provides a 200 MHz analog bandwidth, a single ADC with a maximum sample rate of 1 GSa/s, and a single memory module with 14 Mpts of sample memory. On the other hand, the four-channel version is available in 100 MHz and 200 MHz models, featuring two 1 GSa/s ADCs and two 14 Mpts memory modules. When all channels are active, each channel operates at a sample rate of 500 MSa/s with a standard record length of 7 Mpts. In the case of a single channel per ADC being active, the maximum sample rate is 1 GSa/s, and the maximum record length is 14 Mpts. The front panel design is user-friendly, providing easy access to commonly used functions. The SDS1000X-E series incorporates Super-Phosphor Oscilloscope (SPO) technology for excellent signal fidelity and performance, with lower system noise compared to similar products. It offers a minimum vertical input range of 500 uV/div, an innovative digital trigger system with high sensitivity and low jitter, and a waveform capture rate of 400,000 frames/sec in sequence mode. Additional features include a 256-level intensity grading display function and a unique color temperature display mode. This oscilloscope series supports multiple powerful triggering modes, including serial bus triggering and decoding for IIC, SPI, UART, CAN, and LIN protocols. The XE models include History waveform recording and sequential triggering for extended waveform analysis. A notable addition is the new 1 million points FFT math function, providing high-frequency resolution when observing signal spectra. The digital design incorporates a hardware co-processor for quick and accurate measurements without compromising acquisition and front-panel response. The SDS1000X-E series stands out in its price class, offering unmatched features and performance. The four-channel series includes advanced functions such as searching and navigating, on-screen Bode plot, 16 digital channels (Option), an external USB-powered 25 MHz AWG module (Option), a USB WIFI adapter (Option), and an embedded application for remote control via a web browser. Key Features of the SDS1104X-E, SDS1204X-E, and SDS1202X-E models include: 100 MHz, 200 MHz bandwidth models Two-channel series has one 1 GSa/s ADC, four-channel series has two 1 GSa/s ADCs When all channels are enabled, each channel has a maximum sample rate of 500 MSa/s. When a single channel per ADC is active, it has a sample rate of 1 GSa/s Siglent SPO technology Waveform capture rates up to 100,000 wfm/s (normal mode) and 400,000 wfm/s (sequence mode) Supports 256-level intensity grading and color temperature display modes Record length up to 14 Mpts Digital trigger system with intelligent trigger modes Serial bus triggering and decoding for IIC, SPI, UART, CAN, LIN Video trigger, supports HDTV Low background noise with voltage scales from 500 μV/div to 10 V/div Ten types of one-button shortcuts for various functions Segmented acquisition (Sequence) mode for capturing qualifying events History waveform record (History) function with a maximum recorded waveform length of 80,000 frames Automatic measurement function for 38 parameters and Measurement Statistics, Zoom, Gating, Math, History, and Reference functions 1 Mpts FFT with Peaks and Markers support for four-channel series Math and measurement functions utilize all sampled data points (up to 14 Mpts) Preset key can be customized for user settings or factory defaults Security Erase mode High-speed hardware-based Pass/Fail function MSO, 16 digital channels (four-channel series only, option) Bode plot, Measuring Power Supply Control Loop Response (four-channel series only) Search and navigate (four-channel series only) USB AWG module (four-channel series only, option) USB WIFI adapter (four-channel series only, option) Web Browser-based control (four-channel series only) Large 7-inch TFT-LCD display with 800 * 480 resolution Multiple interface types: USB Host, USB Device (USB -TMC), LAN, Pass/Fail, Trigger Out Supports SCPI remote control commands VXI-11+SCPI, Telnet (Port 5024) +SCPI, and Socket (Port 5025) +SCPI programming over LAN Supports Multi-language display and embedded online help Supports Label (four-channel series only) Supports counter (four-channel series only) Supports data logger including Sample Logger and Measurement Logger (four-channel series only) Supports NTP (Network Time Protocol) (four-channel series only)

Digital Oscilloscope 100 MHz Bandwidth 4 Channels 12 Bit 2GSa/s sample rate 100 Mpts memory depth 10.1" touchscreen SIGLENT’s SDS1000X HD series of high-resolution digital storage oscilloscopes utilize 2 GSa/s, 12-bit Analog-Digital Converters, and front ends known for their exceptional noise floor performance. These oscilloscopes are offered in bandwidths of 200 MHz and 100 MHz, featuring a maximum record length of 100 Mpts and the ability to display 2/4 analog channels alongside 16 digital channels for mixed signal analysis. The SDS1000X HD series incorporates Siglent’s SPO technology, boasting a maximum waveform capture rate of up to 120,000 wfm/s in normal mode (up to 500,000 wfm/s in Sequence mode). These oscilloscopes also feature a 256-level intensity grading display function and a color temperature display mode. An innovative digital trigger system with high sensitivity and low jitter is employed, supporting various powerful triggering modes, including serial bus triggering. Equipped with tools such as History waveform recording, Search and Navigate functions, Mask Test, Bode Plot, and Power Analysis, the SDS1000X HD series allows for the capture, storage, and analysis of extended waveform records. Additionally, these oscilloscopes offer an impressive array of measurement and mathematical capabilities, options for a 25 MHz arbitrary waveform generator, and support for serial decoding. The large 10.1″ capacitive touch screen display supports multi-touch gestures and features a user-friendly UI design, significantly enhancing operational efficiency. Furthermore, it supports mouse control and allows for remote web control over LAN.

125 MHz bandwidth 4 analog channels 16 Digital Channels (PLA2216 logic analyzer probe required) 1.25 GSa/s real-time sample rate 50 Mpts memory depth 12 bit vertical resolution 1,000,000 wfms/s in Ultra Acquire Mode Compact size RIGOL has unveiled its latest addition, the DHO900 series, a digital oscilloscope that combines high performance with affordability, despite its compact design. This series stands out for its exceptional capabilities, including an impressive capture rate of up to 1,000,000 waveforms per second (in UltraAcquire Mode), a generous 50 Mpts memory depth, 12-bit resolution, and minimal noise. What distinguishes the DHO900 series is its support for 16 digital channels, enabling comprehensive analysis of both analog and digital signals, making it an ideal choice for embedded design and testing scenarios. It goes further by offering features like auto serial and parallel bus analysis, bode plot analysis, and various other functions typically reserved for higher-end instruments. Remarkably, all of these features are available at an affordable price point comparable to that of entry-level instruments, making it a versatile solution for meeting testing requirements in fields such as research and development, education, and scientific research. The DHO900 impressively maintains a compact form factor while boasting a wealth of features. A quick comparison with the DHO4000 readily reveals the noticeable difference in size. DHO900 vs DHO4000 DHO900 vs Standard Notebook The small form factor easily allows the DHO900 to be used as a portable handheld instrument that can be powered by a battery bank. Features Ultra-low noise floor, purer signal, never miss the small signals Up to 12 bits resolution for all the models of this series 16 digital channels (std.), logic probe required to be purchased if needed Max. real-time sample rate of 1.25 GSa/s Max. memory depth of 50 Mpts Vertical sensitivity range: 200 μV/div to 10 V/div Max. capture rate of 1,000,000 wfms/s (in UltraAcquire mode) Digital phosphor display with real-time 256-level intensity grading 7" (1024x600) capacitive multi-touch screen Brand new Flex Knob brings a user-friendly experience USB Device & Host, LAN, and HDMI interfaces (std.) for all the models of this series Novel and delicate industrial design, easy to operate Unique online upgrade

70 MHz bandwidth 2 analog channels 12 bit vertical resolution 1 GSa/s Real-time sample rate 50 Mpts max memory depth (100M option available) 50,000 wfms/s waveform capture rate The DHO1000 Series provides improved signal integrity and value with our latest oscilloscope technology. Our UltraVision III platform combined with a new ASIC chip design that provides true 12 bit samples makes the DHO1000 a great solution for benchtop applications where noise and accuracy are paramount. With bandwidths from 70 MHz to 200 MHz, these 2 and 4 channel oscilloscopes have our best signal visualization capabilities. Combine 50-100 Million points of memory, our new Ultra Acquire burst capture mode, and precision measurements for incredible signal fidelity value. The DHO1000 Series is a powerful entry level solution for engineers looking for next generation signal quality and value.

70 MHz bandwidth 2 analog channels Upgradable to 16 digital channels (requires optional PLA2216 logic probe to operate) 8 GSa/s Real Time Sample Rate 100 Mpts Memory Depth (200 Mpts optional upgrade) Waveform Capture up to 500,000 wfms/s The MSO5000 Series Oscilloscopes combine best in class sampling and memory depth with our modern, flexible User Interface enabled by our new UltraVision II architecture and innovative Phoenix Chipset. With 70 to 350 MHz models each with 2 or 4 analog channels, the MSO5000 Series brings innovative flexibility and capability to the engineer's bench. Analyze your critical signals with zone triggering, 7 instruments in 1, Enhanced FFTs, color grading, and histograms all supported by the high sample rate, deep memory, and full memory measurements.

Rigol's DS1104Z Plus is an economical digital oscilloscope. It offers unprecedented value in customer applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The 4-channel, 100 MHz scope has a 7-inch display with Rigol's UltraVision technology, as well as a host of options. 100 MHz bandwidth 4 analog channels Upgradable to 16 digital channels (requires optional RPL1116 logic probe to operate) Real-time sample rate up to 1 GSa/s 24 Mpts with the deep memory option Up to 30,000 wfms/s waveform capture rate Low noise floor, vertical scale range: 1 mV/div to 10 V/div Various interfaces: USB Host&Device, LAN (LXI), AUX Free Options Bundle for all 1000Z Models All options now come standard and factory installed, which includes: serial decode, deep memory, record mode, and advanced triggering. This free bundle is a $450.00 value! Models and Comparisons Model DS1054Z DS1074Z Plus DS1074Z-S Plus DS1104Z Plus DS1104Z-S Plus Analog Bandwidth 50 MHz 70 MHz 100 MHz Number of Analog Channels 4 Number of Digital Channels None DS1000Z Plus supports 16 digital channels after being upgraded with the MSO upgrade option Max. Real-time Sample Rate Analog: 1 GSa/s (1-ch), 500 MSa/s (2-ch), 250 MSa/s (3/4-ch) Digital: 1 GSa/s (8-ch), 500 MSa/s (16-ch) Max. Memory Depth Analog: 24 Mpts (1-ch), 12 Mpts (2-ch), 6 Mpts (3/4-ch) Digital: 24 Mpts (8-ch), 12 Mpts (16-ch) Max. Waveform Capture Rate 30,000 wfms/s Hardware Real-time Waveform Recording and Playback Functions Up to 60,000 frames Standard Probes 4 sets of PVP3150 150 MHz Passive HighZ Probes Built-in 2Ch 25MHz Source No No Yes No Yes

The DS1074Z-S Plus is one of Rigol's economical digital oscilloscopes. It offers unprecedented value in customer applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The 4-channel, 70 MHz, upgradable to MSO version with the purchase of the RPL1116 digital lead kit scope has a 7-inch display with Rigol's UltraVision technology, as well as a host of options. 70 MHz bandwidth 4 analog channels Upgradable to 16 digital channels (requires optional RPL1116 logic probe to operate) Built in 2 channel 25MHz waveform generator Real-time sample rate up to 1 GSa/s 12 Mpts Memory Depth, 24 Mpts with the deep memory option Up to 30,000 wfms/s waveform capture rate Low noise floor, vertical scale range: 1 mV/div to 10 V/div Various interfaces: USB Host&Device, LAN (LXI), AUX Free Options Bundle for all 1000Z Models All options now come standard and factory installed, which includes: serial decode, deep memory, record mode, and advanced triggering. This free bundle is a $450.00 value! Models and Comparisons Model DS1054Z DS1074Z Plus DS1074Z-S Plus DS1104Z Plus DS1104Z-S Plus Analog Bandwidth 50 MHz 70 MHz 100 MHz Number of Analog Channels 4 Number of Digital Channels None DS1000Z Plus supports 16 digital channels after being upgraded with the MSO upgrade option Max. Real-time Sample Rate Analog: 1 GSa/s (1-ch), 500 MSa/s (2-ch), 250 MSa/s (3/4-ch) Digital: 1 GSa/s (8-ch), 500 MSa/s (16-ch) Max. Memory Depth Analog: 24 Mpts (1-ch), 12 Mpts (2-ch), 6 Mpts (3/4-ch) Digital: 24 Mpts (8-ch), 12 Mpts (16-ch) Max. Waveform Capture Rate 30,000 wfms/s Hardware Real-time Waveform Recording and Playback Functions Up to 60,000 frames Standard Probes 4 sets of PVP3150 150 MHz Passive HighZ Probes Built-in 2Ch 25MHz Source No No Yes No Yes

The DS1104Z-S Plus is one of Rigol's economical digital oscilloscopes. It offers unprecedented value in customer applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The 4-channel, 100 MHz, upgradable to MSO version with the purchase of the RPL1116 digital lead kit scope has a 7-inch display with Rigol's UltraVision technology, as well as a host of options. 100 MHz bandwidth 4 analog channels Upgradable to 16 digital channels (requires optional RPL1116 logic probe to operate) Built in 2 channel 25MHz waveform generator Real-time sample rate up to 1 GSa/s 12 Mpts Memory Depth, 24 Mpts with the deep memory option Up to 30,000 wfms/s waveform capture rate Low noise floor, vertical scale range: 1 mV/div to 10 V/div Various interfaces: USB Host&Device, LAN (LXI), AUX Free Options Bundle for all 1000Z Models All options now come standard and factory installed, which includes: serial decode, deep memory, record mode, and advanced triggering. This free bundle is a $450.00 value! Models and Comparisons Model DS1054Z DS1074Z Plus DS1074Z-S Plus DS1104Z Plus DS1104Z-S Plus Analog Bandwidth 50 MHz 70 MHz 100 MHz Number of Analog Channels 4 Number of Digital Channels None DS1000Z Plus supports 16 digital channels after being upgraded with the MSO upgrade option Max. Real-time Sample Rate Analog: 1 GSa/s (1-ch), 500 MSa/s (2-ch), 250 MSa/s (3/4-ch) Digital: 1 GSa/s (8-ch), 500 MSa/s (16-ch) Max. Memory Depth Analog: 24 Mpts (1-ch), 12 Mpts (2-ch), 6 Mpts (3/4-ch) Digital: 24 Mpts (8-ch), 12 Mpts (16-ch) Max. Waveform Capture Rate 30,000 wfms/s Hardware Real-time Waveform Recording and Playback Functions Up to 60,000 frames Standard Probes 4 sets of PVP3150 150 MHz Passive HighZ Probes Built-in 2Ch 25MHz Source No No Yes No Yes

Digital Oscilloscope 2 GHz Bandwidth 4 Analog Channels 16 Digital Channels (Requires SPL2016) 8 Bit Vertical Resolution 5 GSa/s sample rate 500 Mpts Memory Depth 170,000 wfm/s, up to 750,000 wfm/s waveform capture rate in sequence mode 12.1" Capacitive touch screen The SIGLENT SDS6000A series Digital Storage Oscilloscopes offer bandwidth options of 2 GHz, 1 GHz, and 500 MHz. Each channel provides a sample rate of 5 GSa/s (10 GSa/s ESR), a maximum record length of 500 Mpts, and support for up to 4 analog channels plus 16 digital channels for mixed-signal analysis. Utilizing Siglent’s SPO technology, the SDS6000A series delivers a maximum waveform capture rate of 170,000 wfm/s in normal mode and up to 750,000 wfm/s in Sequence mode. It features a 256-level intensity grading display and a color temperature display mode. The advanced digital trigger system ensures high sensitivity and low jitter, supporting various powerful triggering modes, including serial bus triggering. Additional tools such as History waveform recording, Search and Navigate, Mask Test, Bode Plot, Power Analysis, and Eye/Jitter Analysis enable extended waveform capture, storage, and analysis. The oscilloscope also includes extensive measurement and math functions, an optional 25 MHz arbitrary waveform generator, and serial decoding capabilities. A large 12.1-inch capacitive touch screen with multi-touch gesture support, combined with an intuitive user interface, enhances operational efficiency. The SDS6000A also supports mouse control and remote web access via LAN for added convenience.

Digital Oscilloscope 1 GHz Bandwidth 4 Channels 12 Bit 4GSa/s sample rate 400 Mpts memory depth 10.1" touchscreen Get a FREE SDS3000HD-PA option license when you register your product with Siglent. Promotion valid from 2024-11-1 to 2025-04-30. To qualify for the free license, register your new equipment with Siglent at the link. Register Here SIGLENT's SDS3000X HD series of Digital Storage Oscilloscopes are offered in bandwidths of 1 GHz, 500 MHz, and 350 MHz. These oscilloscopes feature 12-bit ADCs with a sample rate of up to 4GSa/s, a maximum record length of 400 Mpts/ch, and the ability to display up to 4 analog channels alongside 16 digital channels for advanced mixed signal analysis. The SDS3000X HD series utilizes Siglent's SPO technology, offering a maximum waveform capture rate of up to 200,000 wfm/s, a 256-level intensity grading display function, and a color temperature display mode. It incorporates an innovative digital trigger system with high sensitivity and low jitter, supporting various powerful triggering modes, including serial bus triggering. Equipped with tools such as History waveform recording, Search and Navigate functions, Mask Test, Bode Plot, and Power Analysis, the SDS3000X HD series enables the capture, storage, and analysis of extended waveform records. Additionally, these oscilloscopes provide a comprehensive range of measurement and mathematical capabilities, options for a 50 MHz arbitrary waveform generator, and support for serial decoding. The generous 10.1" capacitive touch screen display supports multi-touch gestures and features a user-friendly UI design, significantly enhancing operational efficiency. Furthermore, it supports mouse control and allows for remote web control over LAN.

Digital Oscilloscope 3 GHz Bandwidth 4 Analog Channels 16 Digital Channels Optional (Requires SPL2016 and SDS7000A-16LA) 12 Bit Vertical Resolution 20 GSa/s sample rate 500 Mpts Memory Depth 1,000,000 wfm/s waveform capture rate Get a FREE SDS7000-PA option license when you register your product with Siglent. Promotion valid from 2024-11-1 to 2025-04-30. To qualify for the free license, register your new equipment with Siglent at the link. Register Here Siglent’s SDS7000A series of Digital Storage Oscilloscopes is offered in 4 GHz and 3 GHz bandwidth options, featuring 12-bit ADCs with a sample rate of up to 20 GSa/s. These oscilloscopes boast a maximum record length of 1 Gpts/ch and can display up to 4 analog channels along with 16 digital channels, enabling high-performance mixed-signal analysis. Utilizing Siglent’s SPO technology, the SDS7000A series achieves a maximum waveform capture rate of up to 1,000,000 wfm/s. It incorporates a 256-level intensity grading display function and a color temperature display mode. The oscilloscope is equipped with an innovative digital trigger system characterized by high sensitivity and low jitter, supporting various powerful triggering modes, including serial bus triggering. Additional features include tools such as History waveform recording, Search and Navigate functions, Signal Scan, Mask Test, Bode Plot, Power Analysis, Eye/Jitter Analysis, and Compliance Test. These tools facilitate the capture, storage, and analysis of extended waveform records. The SDS7000A series also offers an impressive range of measurement and mathematical capabilities, options for a 50 MHz arbitrary waveform generator, and support for serial decoding. The oscilloscope features a large 15.6-inch HD display with a capacitive touch screen that supports multi-touch gestures. The user-friendly UI design enhances operational efficiency, and the display also supports mouse control. Moreover, the SDS7000A series allows for remote web control over LAN, providing added convenience and flexibility in operation.
