Siglent SSA3032X Plus - 3.2GHz Spectrum Analyzer

Siglent SSA3032X Plus - 3.2GHz Spectrum Analyzer

by Siglent
$3,623.32 - $3,623.32
$3,623.32
$3,623.32 - $3,623.32
$3,623.32
Availability:
Only 1 left!
Download Datasheet

Spectrum Analyzer

  • Frequency Range: 9kHz-3.2GHz
  • RBW 1Hz-1MHz
  • 10.1" Touchscreen
  • -165 dBm/Hz Displayed Average Noise Level (Typ.)
  • -98 dBc/Hz @10 kHz Offset Phase Noise (1 GHz, Typ.)
  • Total Amplitude Accuracy < 0.7 dB
  • 10.1 lnch Multi-Touch Screen, Mouse and Keyboard supported
  • Web Browser Remote Control on PC and Mobile Terminals and File Operation

The SIGLENT SSA3000X Plus series of spectrum analyzers stand out as versatile and robust tools for RF spectrum and signal analysis.

Covering a frequency range up to 7.5 GHz, these analyzers ensure reliable automatic measurements and support various operational modes. The base model functions as a spectrum analyzer, and optional features include RF power measurement, vector signal modulation analysis, reflection measurement, and EMI measurement.

Applications for these analyzers encompass broadcast monitoring/evaluation, site surveying, S-parameter measurement, analog/digital modulation analysis, EMI pre-compliance testing, research and development, education, production, and maintenance.

Key Features and Benefits:
- Spectrum Analyzer Frequency Range: 9 kHz to 7.5 GHz
- Displayed Average Noise Level (Typ.): -165 dBm/Hz
- Offset Phase Noise (1 GHz, Typ.): -98 dBc/Hz @ 10 kHz
- Level Measurement Uncertainty (Typ.): < 0.7 dB
- Minimum Resolution Bandwidth (RBW): 1 Hz
- Preamplifier: Standard
- Tracking Generator: Standard
- Analog and Digital Signal Modulation Analysis Mode: Optional
- Reflection Measurement Kit: Optional
- EMI Measurement Mode: Optional
- Advanced Measurement Kit: Optional
- 10.1-inch Multi-Touch Screen, Mouse, and Keyboard Supported
- Web Browser Remote Control on PC and Mobile Terminals, and File Operation
