Siglent SSA3021X - 2.1GHz Spectrum Analyzer

Siglent SSA3021X - 2.1GHz Spectrum Analyzer

by Siglent
$1,746.34 - $1,746.34
$1,746.34
$1,746.34 - $1,746.34
$1,746.34
Availability:
Only 1 left!
Download Datasheet

Spectrum Analyzer

  • Frequency Range: 9kHz-2.1GHz
  • All-Digital IF Technology
  • -161 dBm/Hz Displayed Average Noise Level (Typ.)
  • -98 dBc/Hz @10 kHz Offset Phase Noise (1 GHz, Typ.)
  • Total Amplitude Accuracy < 0.7 dB
  • 1 Hz Minimum Resolution Bandwidth (RBW)
  • Includes Tracking Generator

Siglent's SSA3000X series of spectrum analyzers cover a frequency range from 9 kHz to 2.1 GHz / 3.2 GHz. These analyzers, characterized by their lightweight, compact size, and user-friendly interface, provide a bright and easily readable display along with robust automatic measurements and numerous features.

Applications for the SSA3000X series span across broadcast monitoring/evaluation, site surveying, EMI pre-compliance, research and development, education, production, and maintenance.

Key Features and Benefits:
- All-Digital IF Technology
- Displayed Average Noise Level (Typ.): -161 dBm/Hz
- Offset Phase Noise (1 GHz, Typ.): -98 dBc/Hz @ 10 kHz
- Total Amplitude Accuracy: < 0.7 dB
- Minimum Resolution Bandwidth (RBW): 1 Hz
- Standard Preamplifier
- Optional Up to 3.2 GHz Tracking Generator Kit
- Optional Reflection Measurement Kit
- Optional Advanced Measurement Kit
- Optional EMI Pre-compliance Test Kit
- 10.1-inch WVGA (1024x600) Display
